TDS2048B-315M Helical Tunable Bandpass Filter

TDS2048B-315M

Product Description

Item Specify
Reference Parts TDS2048B-315M
Acceptable 311～350M
Product Series 7S2
Stock Quantity 0

Detail Electronic Characteristic

Item Specify
Center Frequency 315M
Insertion Loss 2
-3 dB Bandwidth 30M
Sensitivity
(Attenuation)		 F0-(50)Mhz 14
F0+(50)Mhz 19
Return Loss > 12 dB
Impedence In / Out :50 Ω
Ripple < 1 dB

Temperature Condition

Item Specify
Operating Temperature 0C ~60C
Storage Temperature -20C ~ +70C

Mechanical Condtion

Item Specify
Size Diagram 15.2 X 7.6
Height 7.7mm
Input Power 1~5W
