TDS2419B-675M Helical Tunable Bandpass Filter

TDS2419B-675M

Product Description

Item Specify
Reference Parts TDS2419B-675M
Acceptable 661~700M
Product Series 7S2
Stock Quantity 0

Detail Electronic Characteristic

Item Specify
Center Frequency 675M
Insertion Loss 2.5
-3 dB Bandwidth 34M
Sensitivity
(Attenuation)
F0-(100)Mhz 29
F0+(100)Mhz 22
Return Loss > 12 dB
Impedence In / Out :50 Ω
Ripple < 1 dB

Temperature Condition

Item Specify
Operating Temperature 0°C ~ 60°C
Storage Temperature -20°C ~ +70°C

Mechanical Condtion

Item Specify
Size Diagram 15.2 X 7.6
Height 7.7mm
Input Power 1~5W
