TT67136A-940M Helical Tunable Bandpass Filter

TT67136A-940M

Product Description

Item Specify
Reference Parts TT67136A-940M
Acceptable 931~950M
Product Series 7H3
Stock Quantity 0

Detail Electronic Characteristic

Item Specify
Center Frequency 940M
Insertion Loss 5
-3 dB Bandwidth 10M
Sensitivity
(Attenuation)
F0-(50)Mhz 46
F0+(50)Mhz 36
Return Loss > 12 dB
Impedence In / Out :50 Ω
Ripple < 1 dB

Temperature Condition

Item Specify
Operating Temperature 0C ~60C
Storage Temperature -20C ~ +70C

Mechanical Condtion

Item Specify
Size Diagram 22.8 X 7.6
Height 12.5mm
Input Power 1~5W
