TT67345A-960M Helical Tunable Bandpass Filter

TT67345A-960M

Product Description

Item Specify
Reference Parts TT67345A-960M
Acceptable 951~975M
Product Series 7H3
Stock Quantity 0

Detail Electronic Characteristic

Item Specify
Center Frequency 960M
Insertion Loss 3
-3 dB Bandwidth 55M
Sensitivity
(Attenuation)
F0-(100)Mhz 38
F0+(100)Mhz 19
Return Loss > 12 dB
Impedence In / Out :50 Ω
Ripple < 1 dB

Temperature Condition

Item Specify
Operating Temperature 0C ~60C
Storage Temperature -20C ~ +70C

Mechanical Condtion

Item Specify
Size Diagram 22.8 X 7.6
Height 12.5mm
Input Power 1~5W
