TT67447A-895.5M Helical Tunable Bandpass Filter

TT67447A-895.5M

Product Description

Item Specify
Reference Parts TT67447A-895.5M
Acceptable 861~900M
Product Series 7H3
Stock Quantity 0

Detail Electronic Characteristic

Item Specify
Center Frequency 895.5M
Insertion Loss 2
-3 dB Bandwidth 35M
Sensitivity
(Attenuation)
F0-(95)Mhz 15
F0+(50)Mhz 29
Return Loss > 12 dB
Impedence In / Out :50 Ω
Ripple < 1 dB

Temperature Condition

Item Specify
Operating Temperature 0C ~60C
Storage Temperature -20C ~ +70C

Mechanical Condtion

Item Specify
Size Diagram 22.8 X 7.6
Height 12.5mm
Input Power 1~5W
