TF69463E-465M Helical Tunable Bandpass Filter
Product Description
| Item | Specify |
|---|---|
| Reference Parts | TF69463E-465M |
| Acceptable | 456～515M |
| Product Series | 7H4 |
| Stock Quantity | 0 |
Detail Electronic Characteristic
| Item | Specify | |
|---|---|---|
| Center Frequency | 465M | |
| Insertion Loss | 4.5 | |
| -3 dB Bandwidth | 10M | |
| Sensitivity (Attenuation) |
F0-(50)Mhz | 60 |
| F0+(50)Mhz | 55 | |
| Return Loss | > 12 dB | |
| Impedence | In / Out :50 Ω | |
| Ripple | < 1 dB | |
Temperature Condition
| Item | Specify |
|---|---|
| Operating Temperature | 0°C ~ 60°C |
| Storage Temperature | -20°C ~ +70°C |
Mechanical Condtion
| Item | Specify |
|---|---|
| Size Diagram | 30.5 X 7.6 |
| Height | 12.5mm |
| Input Power | 1~5W |
