TT6720B-351M Helical Tunable Bandpass Filter

TT6720B-351M

Product Description

Item Specify
Reference Parts TT6720B-351M
Acceptable 311~355M
Product Series 7H3
Stock Quantity 0

Detail Electronic Characteristic

Item Specify
Center Frequency 351M
Insertion Loss 5
-3 dB Bandwidth 6M
Sensitivity
(Attenuation)
F0-(20)Mhz 43
F0+(20)Mhz 30
Return Loss > 12 dB
Impedence In / Out :50 Ω
Ripple < 1 dB

Temperature Condition

Item Specify
Operating Temperature 0°C ~ 60°C
Storage Temperature -20°C ~ +70°C

Mechanical Condtion

Item Specify
Size Diagram 22.8 X 7.6
Height 12.5mm
Input Power 1~5W
