TTR3815B-1525M Helical Tunable Bandpass Filter
Product Description
| Item | Specify |
|---|---|
| Reference Parts | TTR3815B-1525M |
| Acceptable | 1501～1550M |
| Product Series | 5R3 |
| Stock Quantity | 0 |
Detail Electronic Characteristic
| Item | Specify | |
|---|---|---|
| Center Frequency | 1525M | |
| Insertion Loss | 4.5 | |
| -3 dB Bandwidth | 28M | |
| Sensitivity (Attenuation) |
F0-(100)Mhz | 34 |
| F0+(100)Mhz | 26 | |
| Return Loss | ||
| Impedence | In / Out :50 Ω | |
| Ripple | ||
Temperature Condition
| Item | Specify |
|---|---|
| Operating Temperature | 0C ~60C |
| Storage Temperature | -20C ~ +70C |
Mechanical Condtion
| Item | Specify |
|---|---|
| Size Diagram | 16.8 X 5.6 |
| Height | 8.6mm |
| Input Power | 1~5W |
